PERFORATED SHEETCarbon Steel

Carbon Steel EN8 (C45) PERFORATED SHEET

Also known as: AISI 1045 / UNS G10450 / 1.0503 / C45 / S45C

1mm Thick X 1524mm Width X 3048mm Length X 0.3mm Perforation X 0.8mm Pitch

Available in Unknown

Ratings & Performance

0.0
Product Rating
-100%
Acceptance Rate
0%
Return Rate
0.0
Weight Accuracy
5.0
Seller Rating
18%
Seller Acceptance
0%
Seller Return
Verified Seller
GST Invoice
8 viewing now
Last ordered 40d ago

Specifications

Thickness

1 mm

Width

1524 mm

Length

3048 mm

Finish

Standard / Unknown

Make

Local make

PMI

PMI NOT DONE

Product Details

Shape

PERFORATED SHEET

Sheet and plates with holes punched in it

Material

Carbon Steel

Steel with a higher carbon content than mild steel, offering increased strength and hardness. Used in structural applications and machinery parts.

Grade

EN8 (C45)

Standard: DIN C45 / EN8 / 1.0503

MOQ

10 kg

Plain carbon steel for general purposes.

Chemical Composition — EN8 (C45)

CPSMnSi
0.40-0.500.040 max0.040 max0.60-0.900.15-0.35

Mechanical Properties — EN8 (C45)

hardness

197-241 HB

elongation

14% min

yield_strength

350 MPa min

tensile_strength

630-780 MPa

International Equivalents — EN8 (C45)

ASTM: AISI 1045 / UNS G10450 (USA)
DIN/EN: 1.0503 / C45 (Germany)
JIS: S45C (Japan)
IS: IS C45 / IS 1570 (India)

Equivalent Standard Chemistry

ASTM AISI 1045 / UNS G10450

CPSFeMnSi
0.43-0.500.040 max0.050 maxBalance0.60-0.900.15-0.35

DIN/EN 1.0503 / C45

CPSCrFeMnMoNiSi
0.42-0.500.030 max0.035 max0.40 maxBalance0.50-0.800.10 max0.40 max0.40 max

JIS S45C

CPSCrCuFeMnNiSi
0.42-0.480.030 max0.035 max0.20 max0.30 maxBalance0.60-0.900.20 max0.15-0.35

IS IS C45 / IS 1570

CPSFeMnSi
0.40-0.500.040 max0.040 maxBalance0.60-0.900.10-0.35

Price /kg

₹55/kg

Total: ₹2,074(37.7 kg × ₹55)

+ Add-ons + GST & Transport on actual basis

Buy In:

Best Bulk Rate: ₹52.00/kg

Order more to unlock lower rates

Select Quantity

Adjusted:
1
PCS
50
SQFT
37.7
KG

Customisation Available

105mm — 1220mm
mm

Available Services & Charges

Packing & Forwarding
Compulsory
₹1/kg (min ₹100)
PMI Testing
Optional
₹200/pc
UT Testing
Optional
₹200/pc
Lab Testing
Optional
₹200/pc
NABL (Chemical)
Optional
₹200/pc
NABL (Chem + Physical)
Optional
₹200/pc
Available Add-Ons:
Packing and forwarding
PMI
Sample Lab Testing
NABL (chemical only)
NABL (chemical + physical)

Stock Location

Unknown, Unknown

Frequently Asked Questions

About 1mm Thick X 1524mm Width X 3048mm Length X 0.3mm Perforation X 0.8mm Pitch EN8 (C45) PERFORATED SHEET & MetaleMart
